Fast / Compact / Flexible UNIGATE FALCON Protocol Converter/Gateway Series. The new UNIGATE FALCON series connects devices such as automation components to the desired Industrial Ethernet standard or fieldbus via their serial interface. RS232/RS485/RS422 interfaces are integrated as standard. Communication between the serial connection and/or Industrial Ethernet/fieldbus is established either through device configuration or via a script. Standard protocols such as Modbus ASCII, Modbus RTU (Master or Slave), 3964 (R), and others can be configured via the UNIGATE FALCON web interface. Scripts can be created using the free PC software tool 'Protocol Developer'. A script offers maximum flexibility for complex tasks and enables, for example, the implementation of proprietary protocols. Custom scripts can be developed based on the available template scripts. Deutschmann Automation also offers script creation as a service. The new UNIGATE FALCON series is available as a DIN rail module (IP20) or as an embedded version for direct integration into existing end products. The very slim and compact device even allows for installation in a sub-distribution board. All modules for the different bus variants have an identical mechanical design, meaning they can be used flexibly or replaced without additional effort. This allows for the delivery of end devices with any desired bus for optimal integration into the environment. Another feature is the integrated service functions, which can be accessed via a button on the front of the device. Without any additional equipment, a hardware reset or a factory reset can be performed.
