With STEIN Link, we have developed an innovative shuttle system that makes internal material flow more flexible and efficient. The focus is on maximum adaptability, easy integration, and future-proofing—features that are crucial for modern assembly and logistics processes.
The system transports workpiece carriers, crates, or customer-specific superstructures with a payload of up to 80 kg at a speed of up to 50 m/min – directly on the shuttle. A robust aluminum T-profile ensures high tilt stability and smooth running even with off-center loads.
A key advantage is the wireless power supply: The shuttles do not require power rails or energy supply along the route. Replaceable batteries ensure the power supply; when the charge level is low, the shuttle automatically drives to the exchange station. The battery can be changed manually or automatically. A battery management system continuously monitors the charge level and ensures maximum availability.
RFID tags define logical sections for position and route control. Central software regulates traffic flow, entry permissions, and speed—depending on route occupancy and priorities. In addition, proximity sensors on the shuttle ensure gentle braking when obstacles are encountered.
The system has a modular design: switches, curves, lifts, and locks can be easily added. Installation requires only a few screws and can even be done under the ceiling to save space. This makes STEIN Link particularly suitable for retrofit applications or systems with frequent layout changes.
The result is a scalable, low-maintenance, and future-proof conveyor system with minimal cabling. STEIN Link helps companies make their processes more efficient, sustainable, and flexible—an innovative contribution to the factory of the future.
