Advanced direct reflective photoelectric sensors
E3AS Series changes the “way of using” photoelectric sensors
– Wide range of solution up to 1,5m.
– High reliable detection for shiny, uneven & transparent objects.
– Spot beam and Line beam to detect any challenging object.
– Transparent detection objects without reflector.
– OLED display for easy navigation & advance adjustments.
– Compact-sized body can be mounted anywhere.
– Manufactured using OMRON’s proprietary laser sealing method.
– IP67/IP69K/IP67G.
– Antifouling coatings reduce the cleaning frequency on the sensing surface.
– IO-Link reduces the time required for start-ups and changeovers.
– Air blow accessory for easy maintenance.
– Equipped with OMRON’s proprietary light emitting element for stable detection of low-reflective. workpieces.
TOF method enables detection of various workpieces on the conveyor line
With conventional photoelectric sensors, prior evaluation was required for each workpiece to be detected. E3AS-F Sensors detect workpieces varying in colors and materials by the set distance. This helps reduce evaluation and adjustment time. Also, they do not detect workers working near the line by mistake.
Antifouling coating prevents contamination on the sensing surface
Dirty sensing surface can cause false detection due to the principle of photoelectric sensors. E3AS Series with the antifouling coating on the sensing surface, which is the industry’s first, prevents water droplets, oil, and dust from sticking to the sensing surface, and keeps the lens from fogging as well. Therefore, the coating prevents contamination on the sensing surface in environments where oil or dust scatters, or steam generates. False detection and cleaning frequency are also reduced.
